POE power to IR LED & Camera, heater

Integrated POE splitter 30W, 12V DC output to camera

Accurate constant circuit drive develops excellent performance of LED

Using high power LED, high efficacy and long service life

Improve performance of camera to get better pictures at night time

Fill Light for night vision camera

Indoor/Our door use

Easy installation IP Camera and mega pixel camera

Specification

Quantity of LED 8pcs 2W high power LED

Wavelength 850nm

Beam angle 15°/30°/45°/60°/90°/120°

Viewing distance 140~25m

Day/night switch Auto

Working voltage POE IEEE 802.3at

Power consumption 30W (power of LED, blower and IP camera)

Cable Cat.5e 45cm (1.4 ft.)

Output to camera DC12V

Panel Tempered glass panel

Housing Aluminum Die Casting Housing

Bracket Mount bracket

Working temperature -20 to 50°C (-50 to 50°C with heater)

Protection Level IP65

Color White

N.W 2.7KG

G.W 3.4KG

Dimension 390*172*155mm

Packing Dimension 450*265*225mm

Models for Selection

Model Viewing Distance Angle

SD8P-15-IR 140m 15°

SD8P-30-IR 100m 30°

SD8P-45-IR 80m 45°

SD8P-60-IR 70m 60°

SD8P-90-IR 40m 90°

SD8P-120-IR 25m 120°
