Deliver high power white light for CCTV & IP camera at night time and improve performance of camera to get colorful pictures.

Product Features

Precise secondary optical technology. The latest LED technology assures outstanding performance of LED with excellent luminous efficiency and more uniform illumination.Independent innovation of high efficiency power drive schemes.Low failure rate of products is guaranteed because of professional in-house optimized independent circuit technology widely used in our LED illuminators for more than 5 years.High thermal conductivity aluminum.Excellent thermal management not only reduces excess heat and brightness decay of LED but also ensures efficient, reliable and continuous operation of LED throughout its lifetime as 50,000 hours.Energy saving technology.All illuminators has energy saving circuit with low electrical power consumption. Thinner and lighter design.Our patent owned housing is designed for simple installation and easy operation to reduce construction difficulty.Warranty period:3 year warranty.

Basic Function

To improve performance of the weak light camera, thereby enhancing the picture effects at night. Conventional night monitoring.The function of video analysis at night.Reduce signal noise and other image distortion. Reduce the network bandwidth requirements.Energy saving by power factor correction. Reduce the equipment cost. Lower cost of installing and wiring.Indoor and outdoor use.

Description

Accurate constant circuit drive develops excellent performance of LED;The latest generation dot matrix IR LED,high efficacy and long service life; Fill Light for night vision camera Indoor/Outdoor use. Easy installation

Specification

Quantity of LED: 3PCS 2W High Power IR LED

Wavelength: 850nm

Beam Angle: 160°

Viewing Range: 150m2 (3-5mtrs)

Operation Mode: CDS light control

Working Voltage: DC12V

Current: 500mA

Wire: If 12VDC/24VAC:45cm(1.4 ft.)

Working temperature: -30℃ TO +50℃

Protection Level: IP65

Color: Silver

N.W: 0.33KG

G.W: 0.4KG

Models for selection

Model Beam Angle Viewing Range(850nm)

F8150-160-C-IR 160° 150m² (3-5mtrs)

Viewing distance is tested by 1/3 SONY B/W CCD Camera, it''''s depending on camera and lens.
