Description

Accurate constant circuit drive develops excellent performance of LED

Using high power LED, high efficacy and long service life

Improve performance of camera to get better pictures at night time

Fill Light for night vision camera

Indoor/Our door use

Easy installation

Specification

Quantity of LED 3PCS 2W High Power LED

Wavelength 850nm

Bean Angle 15°/30°/45°/60°/90°

Viewing Distance 100~15m

Day/night Switch Auto

Working Voltage AC110-220V/AC24V/DC12V

Power consumption 12W

Wire If 12VDC/24VAC:45cm(1.4 ft.)

Plug AC110-220V (standard), other voltage optional

Panel Tempered glass panel

Housing Aluminum Die Casting Housing

Bracket Mount bracket

Working temperature -20°C TO +50°C

Protection Level IP65

Color White

N.W 2.6KG

G.W 3.25KG

Dimension 390*172*155mm

Packing Dimension 440*270*220mm

Model Bean Angle Viewing distance

SD6/R15AW 15° 120m

SD6/R30AW 30° 80m

SD6/R45AW 45° 60m

SD6/R60AW 60° 40m

SD6/R90AW 90° 15m

Actual viewing distance is depended on the performance of camera and lens.
