1. Adopt high-performance UHF RFID chips, read and write distance up to 60

meters. Multi tag reading up to 800 tags/second

2. With high stability;

3. The protection grade could reach IP67.

4. The large capacity battery, long runs.

5. 1.2 meters fall protection.

6. Touch screen: full toughened capacitive touch screen surface hardness

greater than 8 h, 400 CD/M2 brightness visible in the sunlight.

Product Technical parameters:

Operating frequency 2.4GHz~2.5GHz ISM

RF power range -30dBm~0.0dBm( adjusted by 32 grade )

Receiving sensitivity -90.0dBm

Reading range: 0~60m (Adjustable depending on different gain

omni-directional antenna,)

Anti-collision: Up to 800 tags read simultaneously

Communication speed:250kbps, 1Mbps, 2Mbps(adjustable)2

Size 209*139*20mm（L×W×H）

Weight(g) : 590g

CPU QualcommMSM8916, A53, 4 core CPU,

1.2GHz

Built-in storage 2 GB RAM + 16 GB Flash

2G/3G/4G ROM 16G-W FDD-LTE/TDD-LTE/WCDMA/GSM

FDD-LTE:1800/2100/2600 B1/B3/B7

TDD-LTE:B38/B39/B40/B41

B38:2570-2620MHz

B39:1880-1920MHz

B40:2300-2400MHz

B41:2555-2575MHz

2575-2635MHz

2635-2655MHz

WCDMA: 850/1900/2100 B1/B2/B5

GSM : 900/1800/1900 B2/B3/B8

2G/3G/4G CDMA 1X/EVDO BC0

GSM 850/900/1800MHZ

WCDMA B1/B5/B8

TD-SCDMA B34/B39

FDD-LTE:B1/B3/B7

TD-LTE：B38/B39/B40/B4

Phone SIM card interface: support,common1.8/3.3V SIM card

OS Android 5.1

Navigation and positioning built-in GPS Satellite-navigation chips, support

A-GPS,EPO

RFID Support functions of uhf RFID, read

range up to 10m

2D scanner Optional

OTG Support

FM radio Support

Bluetooth BT4.0 (A2DP+EDR)

Motion sensor Support

Gravity sensor Support

Geomagnetic sensor Support3

Gyro Sensor Support

Trumpet 20x30 Membrane type speaker unit

Network connections 3G/4G

Communication WCDMA 3.75G (HSDPA+ 42.2Mbps,

HSUPA+

11.5Mbps), support WIFI route sharing

EDGE : Support

GPRS Support

WAP Support

WI-FI Support

Main display 7.0”hd IPS/AFFS display 1024 * 600

600 CD/m2 visual highlight the sun.

Touch screen G + G 5 full toughened high strength

capacitance touch screen

Main camera 5 million pixels with af and electronic

flash

Deputy camera 2 million megapixel camera

External memory expansion Micro SD card (T - FLASH card) card

reader, maximum support 64 GB

extension

Battery 7200 mAh

Charging interface USB Micro 5 pin

Data interface USB Micro 5 pin

Headphone jack 3.5 mm

Language English, Spanish, Portuguese (Brazil),

Portuguese (podcast), Italian, German,

Dutch, French, Polish, Romanian,

Turkish, the Russian, Arabic,

Indonesian, Malay,Thai, Vietnamese,

Hindi, Hebrew, Simplified Chinese
