.Scanning Frequency:NTSC: 15,734KHz(H), 60Hz(V);PAL: 15,625KHz(H),50Hz(V)

.Scanning System:NTSC: 525 line 2:1 interlace PAL:625 lines 2:1 interlace

.Effective Pixels:NTSC: 512(H) x 492(V);PAL:512(H) x 582(V)

.Electronic Shutter:N:1/60- 1/100,000 sec (Auto);P:1/50-1/100,000sec (Auto).

.Horizontal: 420 TV Lines

.White-balance:Auto

.white balance: (2500K~9500K)

.Synchronizing System:Internal

.Sensitivity:0.2 Lux/ F2.0 ( 1/3〃)

.BLC:Auto

.Signal to Noise:More than 48dB AGC off

.AGC:YES

.Gamma Correction:0.45

.IR Distance:N/A

.IR LED:N/A

.IR Status:N/A

.IR View Angle: N/A

.IR Wavelength: N/A

.LED Life: N/A

.Lens: 4.3 mm Board Lens (6,8mm Option)

.Power Consumption:120mA∮5mA

.Power Supply:12V DC ∮ 10%

.Temperature: Operating: -10 to 50C

.Video Output Composite:1.0 Vp-p at 75 ohm

.Construction:Aluminum

.Dimensions:57(W) x 47(H) X 93(L) mm

.Weight:230 g
