.Effective Pixels:NTSC: 512(H) x 492(V); PAL:512(H) x 582(V)

.Electronic Shutter:N:1/60- 1/100,000sec(Auto);P:1/50-1/100,000sec.(Auto)

.Horizontal:420 TV Lines

.White balance:Auto white balance ( 2500K~9500K)

.Synchronizing System:Internal

.Sensitivity:0.2 Lux / F2.0 (1/3〃) 0.7 Lux F2.0 (1/4〃)

.BLC:Auto

.Signal to Noise:More than 48dB (AGC off)

.AGC:Yes

.Gamma Correction:0.45

.Lens:4 mm Standard (6,8mm Option)

.Power Consumption:120mA ∮ 5mA

.Power Supply:12V DC ∮ 10%

.Temperature:Operating: -10 to 50C

.Video Output:Composite 1.0 Vp-p at 75 ohm

.Construction:Plastic

.Dimensions:86 (№) x 64(H) mm

.Weight:160 g
