.Scanning Frequency: NTSC: 15,734KHz(H), 60Hz(V);PAL: 15,625KHz(H),50Hz(V)

.Scanning System: NTSC: 525 line 2:1 interlace PAL:625 lines 2:1 interlace

.Effective Pixels:NTSC: 512(H) x 492(V);PAL:512(H) x 582(V)

.Electronic Shutter: N:1/60- 1/100,000 sec (Auto);PAL:1/50-1/100,000sec (Auto)

.Horizontal:420 TV Lines

.White-balance:Auto

.white balance:(2500K~9500K)

.Synchronizing System:Internal

.Sensitivity:0.1 Lux , 0 Lux at IR on / F2.0

.BLC:Auto

.Signal to Noise: More than 48dB

.AGC:off

.AGC:Yes

.Gamma Correction:0.45

.IR Distance:50 Meters (Max.)

.IR LED:8 pcs Enhanced Power LED +10 pcs normal LED

.IR Status:Under 10 Lux by CDS auto control

.IR View Angle:View angle: 70,Beam spread: 40/per LED

.IR Wavelength: 850nm ∮ 25nm

.LED Life: More than 10,000 hours

.Lens:12mm Standard (4,8,16mm Option)

.Power Consumption:IR on: 450mA, IR off: 120mA ∮ 5mA

.Power Supply:12VDC, 24VAC, 90V~260VAC (Auto)

.Temperature:Operating: -10 to 50C

.Video Output:Composite 1.0 Vp-p at 75 ohm

.Construction:Aluminum with sunshield weatherproof

.Dimensions:151(W) x 145(H) x 390(L) mm

.Weight:will advise later
