.Scanning Frequency:NTSC: 15,734KHz(H), 60Hz(V);PAL: 15,625KHz(H),50Hz(V)

.Scanning System:NTSC: 525 line 2:1 interlace PAL:625 lines 2:1 interlace

.Effective Pixels:NTSC: 512(H) x 492(V);PAL:512(H) x 582(V)

.Electronic Shutter: N:1/60- 1/100,000 sec (Auto); PAL:1/50-1/100,000sec (Auto)

.Horizontal:420 TV Lines

.White-balance:Auto white balance (2500K~9500K)

.Synchronizing System:Internal

.Sensitivity:0.1 Lux , 0 Lux at IR on / F2.0

.BLC:Auto

.Signal to Noise:More than 48dB AGC off

.AGC:Yes

.Gamma Correction:0.45

.IR Distance:15 Meters (Max.)

.IR LED: 28 pcs LED

.IR Status:Under 10 Lux by CDS auto control

.IR View Angle: View angle: 70, Beam spread: 40/per LED

.IR Wavelength:850nm ∮ 25nm

.LED Life:More than 10,000 hours

.Lens:6mm Standard

.Power Consumption:IR on: 450mA, IR off: 120mA ∮ 5mA

.Power Supply:12VDC

.Temperature:Operating: -10 to 50C

.Video Output:Composite 1.0 Vp-p at 75 ohm

.Construction:Aluminum with sunshield weatherproof

.Dimensions:70(O) x 120(L) mm

.Weight:400 g
