.Scanning Frequency: NTSC:15,734KHz(H), 60Hz(V);PAL: 15,625KHz(H),50Hz(V)

.Scanning System:NTSC: 525 line 2:1 interlace PAL:625 lines 2:1 interlace

.Effective Pixels: NTSC: 512(H) x 492(V); PAL:512(H) x 582(V)

.Electronic Shutter: N:1/60- 1/100,000sec (Auto);P:1/50-1/100,000sec (Auto)

.Horizontal:420 TV lines

.White-balance:Auto white balance (2500K~9500k)

.Synchronizing System:Internal

.Sensitivity: 0.2 Lux , 0 Lux at IR on / F2.0

.BLC:Auto

.Signal to Noise: More than 48dB (AGC off)

.AGC:Yes

.Gamma Correction: 0.45

.IR Distance: 30 Meters (Based on: object of view reflected IR light)

.IR LED: High Light LED x 24 pcs

.IR Status:Under 10 Lux by CDS auto control

.IR View Angle:View angle: 70, Beam spread: 40/per LED

.IR Wavelength: 850nm ∮ 25nm

.LED Life:More than 10,000 hours

.Lens:6 mm Standard (4,8,12,16mm option)

.Protection Class:IP 66 classification

.Power Consumption: IR on: 450mA, IR off: 120mA (DC 12V) ∮ 5mA

.Power Supply:DC 12V, AC 90V ~ 260V (Auto)

.Temperature:Operating: -10 to 50C

.Video Output:Composite 1.0 Vp-p at 75 ohm

.Construction:Aluminum with sunshield weatherproof

.Dimensions:110(W) x 100(H) X 330(L) mm

.Weight:1300 g
