*Unique design and stunning appearance.

*Distinguishable audiovisual indication of colorful LED and multi-tone beeper which can also be controlled individually by the host system.

*Large LCD with backlight for displaying card''s number and status.

*Can setup the Date, Time, Reader ID, Multilingual, backlight.

*Tamper switch built-in for vandal resistance.

*Self-test on reader power-up to verify the setup configuration and initialize reader operation.

*Compatible with SYRIS NT series controller.

SPEC.

Frequency 125KHz/13.56MHz

Read range 2cm-10cm (Mifare typy:2cm-8cm)

Card read time 0.1 sec (Typical)

Output interface RS485 format and Wiegand format

Input points Normally 4 Data input points

LCD display 128x64 Dot (16x4 Char)

Keypad 4 key / 16 key

Bell 16 sets of timer:Active time 1sec~250sec

Power supply 8V to 20V DC

Language Multi-language (English/T-Chinese/S-Chinese)

Color Gray/Green/Yellow

Dimensions(mm) 99.6W x 150.85H x 30.75D
