*Extended Read Range

*Multi-Tag Capability

*Compact Low-Cost Design

*Simplified Installation

SPEC.

>>System SPEC.

communication 2.45GHz Support read and write

Frenquency 2.40~2.48GHz

Channel 255

Address 65536

RSSI 0-255

LQI 0-255

LED Reader action or R/W status

>>Interface SPEC.

RS232 PX, TX

USB V1.1 Fully Compliant with USB Specification V2.0

(Full-Speed)

Rs485 +,-

Baud Rate 2400bps~115200bps

>>Power Require

USB 5VDC

RS232 3.5VDC~12VDC

RS485 7VDC~18VDC

Action Current 100mA@5 VDC MAX

>>Others

Operating -20 oC to 65 oC, 5 to 95%RH

Storage -30 oC to 85 oC, 5 to 95%RH

Dimensions 92W x 66H x 20D (mm)
