*Extended Read Range

*Multi-Tag Capability

*Compact Low-Cost Design

*Simplified Installation

SPEC.

>>System SPEC.

communication 2.45GHz Support read and write

Frenquency 2.40~2.48GHz

Channel 256

Address 65536

RSSI 0-255

LQI 0-255

LED Reader action or R/W status

>>Interface SPEC.

RS232 PX, TX

Ethernet 10 BASE-T/100BASE-TX port, 10/100Mbps

Protocols ICMP, ARP, IP, TCP, UDP, DHCP, HTTP

Rs485 +,-

Baud Rate 2400bps~115200bps

>>Power Require

Power Input 7.5VDC~28VDC

Action Current 50mA@3 VDC MAX

>>Others

Operating -20 oC to 65 oC, 5 to 95%RH

Storage -30 oC to 85 oC, 5 to 95%RH

Dimensions 107W x 138H x 30D (mm)
