*Extended Read Range

*Multi-Tag Capability

*Compact Low-Cost Design

*Simplified Installation

SPEC.

>>System SPEC.

communication 2.45GHz Support read and write

Frenquency 2.40~2.48GHz

Channel 256

Address 65536

RSSI 0-255

ID 64 bits

Program Set parameter

LED Tag action or R/W status(hidden in housing)

Memory 4K bytes ~ 32K bytes (option)

TEMP. (option)

Beeper (option)

Tamper Switch (option)

>>Power Require

Battery 3VDC CR2032

Battery life 1 year ~ 7 year

Action Current 24mA@3 VDC @0.5ms

>>Others

Operating -20 oC to 65 oC, 5 to 95%RH

Storage -30 oC to 85 oC, 5 to 95%RH

Dimensions 42W x 30H x 10D (mm)
