Listing Description:

- Low price,

- Easy installation and connection,

- Stand-alone and network operation,

- Protection against improper connection,

- Select the type of lock,

- Mode ACCEPT,

- Mode Locking.

Specifications:

- Power supply: 8-18V DC

- Current consumption: 20mA

- Quantity of connected readers: 2pcs.

- Type (protocol) plug-readers: Dallas Touch Memory

- TIR transistor outputs: 1pc.

- Switching current: 5A

- Number of keys / cards (max): 2024 pc.

- Number of stored events (max): 2048 pc.

- The communication protocol controllers: RS485

- Communication speed: 19200bod/57600bod

- Maximum line length: 1200m

- Operating temperature: -40°C to +50°C (except battery)

- Size (mm): 65x65x18

Modes:

* ACCEPT-mode allows you to restore the database keys. By stepping mode ACCEPT controller allows access to all keys and stores them at the same ID in its memory. Thus, after a few days in the mode of ACCEPT, the controller generates a new key database.

* Blocking Mode - control access authorization. Blocking key enables or disables the opening of the door the rest spelled keys. Lock mode is useful in cases where it is necessary to meet a condition in which you can not enter the premises if there is no responsible person (owner of the blocking key).
