■ Features:
. 2.0 MegaPixel Micron DigitalClarity?CMOS
. H.264 /MPEG-4/MJPEG video compression.
. Up to UXGA resolution at 15fps
. Supported HD 720(1280x 720) resolution at real time.
. Support ONVIF
. Support Fisheye function
■ Main General Features
. System: SoC Embedded ARM-Linux
. Resolution: 1600x1200@15fps, 1280x720 @ 30fps, 800x600 @30fps
. Support 2.0 Mega Pixel CMOS sensor module
. Support 50/60 Hz frequency
. Compression: H.264 / MPEG-4 / MJPEG for video
. Adjustable video data rate
. Synchronized video compression
. Simultaneously multiple clients service more than 5Mbps streaming out Maximum 5 users view.
. Factory setting reset
. Protocol Supported: DHCP, PPPoE, Dynamic DNS, TCP/IP, UDP, SMTP, UPnP, HTTP, HTTPS, RTSP, DNS client, SNMPv1/v2c, SIP
. Support HTTP Tunneling (RTSP over HTTP)
. Provide Dynamic IP server platform for dynamic IP user
. Watch Dog Timer function
. IE Browsing supported (ActiveX?)
. Support NTP time Setting
. Message in e-mail
. Provide RTC (Real Time Clock) function
. Hardware OSD of time display
. Support Day & Night function
. Support Daylight Saving Time
■ General Features
. Provide scheduling, recording, event list, management, playback, transmitting, recycle
. Provide 1/4/6/9/10/13/16/33/64 CH Window Display
. HTTP port setting
. Snapshot, Motion Detect Recording, I/O Recording
. Auto Recovery when disconnected.
. Support Digital Zoom in/out on Preview and Playback
. Programmable IP / Subnet / Gateway (IE)
. Motion Detection Sensitivity: 1~9 (IE)
. Event: Motion Detect, Video Loss, Digital input(IE)
. Action: E-mail and ftp alarm out. (IE)
. Firmware upgrade over Ethernet (IE)
. Video quality setting: Contrast, Brightness, Saturation, Hue (IE)
. Windows XP/Vista/7 required ( DirectXTM 9.0C or Higher)
. Support Windows Internet Explorer 6.0 / 7.0 / 8.0
. Support DivX format
. Language Support : English, French, German, Japanese, Italian, Spanish, SimplifiedChinese, Traditional Chinese
. Support IPCAM alarm trigger (Motion/Digital I/O, Video Loss) by MSN send message.
