?Support D1 resolution(at recording to SD card)

?Can support wide range of power input (DC +8V ~ +36V, AVR, Automatic Voltage Regulator).

?Some period of delay before shut down (after backup is completed)

?Provide playback software to play recorded files on SD card.

?Provide external USB-HDD backup by transferring files from SD card (Optional function)

?Extendable to 8, 12, 16 CH

■ Features(GPS Tracker part)

. Support GSM –Quad band: 850/900/1800/1900 MHZ

. Support GPRS multi-slot class 10 and mobile station class B

. GPS data conformed to NMEA 0183 format

. by TCP protocol, GPS data can be transferred to backend CMS(Center Management System) software timely

. 2 digital inputs

. SOS emergency button function

. timely track GPS data by transferring GPS data to backend CMS software

. the maximum number of GPS trackers is unlimited controlled by CMS software

. LED indicators, power, GSM/GPRS status, GPS status

. built-in G-sensor function, alarm will be sent to backend CMS software if the measured G value of axis X, Y or Z exceeds the thresholds set by users. User can adjust the threshold values for axis X, Y, Z to simulate some situations, for example, crash, upside down.

. view by smart phones

.Battery: 3.7V(internal battery)

■ Main Features(MVR part)

.System: SoC, Embedded ARM-Linux

.Resolution: 720x480/ 320x 240 .

Compression: H.264 / MPEG-4 / JPEG for video

.Adjustable video data rate

.Adjustable audio data rate

.Synchronized video + audio compression

.Factory setting reset

.Protocol Supported: DHCP, TCP/IP, UDP, UPnP, HTTP, RTSP, HTTP tunneling

.Watch Dog Timer function

.IE Browsing supported (ActiveX?)

.Support NTP time setting

.Provide RTC (Real Time Clock) function

.Hardware OSD of time display

■ Main Features(MVR part)

.HTTP port setting, Audio can be disabled (IE)

.Snapshot (IE)

.Auto Recovery when disconnected.(IE)

.Programmable IP / Subnet / Gateway (IE)

.Event: Video Loss(IE)

.Firmware upgrade over Ethernet (IE)

.Video quality setting: Contrast, Brightness, Saturation, Hue (IE)

.Windows XP/Vista/7 supported, and DirectX? 9.0C or Higher required

.Support Windows Internet Explorer 6.0 / 7.0 / 8.0

.Language : English, Traditional Chinese

.Support alarm trigger
