. 2.0" Micron DigitalClarity? CMOS

. H.264 / MJPEG video compression.

. Up to UXGA resolution at 15fps

. Supported HD 720(1280x 720) resolution at real time.

. Micro SD & USB Pen-drive event image capture supported

. Two way audio supported

■ Main General Features

. System: SoC Embedded ARM-Linux

. Resolution: 1600x1200@15fps, 1280x720 @ 30fps

. Support 2.0 Mega Pixel CMOS sensor module

. Support 50/60 Hz frequency

. Compression: H.264 / MJPEG for video

. Adjustable video data rate

. Adjustable audio data rate

. Synchronized video + audio compression

. Factory setting reset. Protocol Supported: DHCP, PPPoE, Dynamic DNS, TCP/IP, UDP, SMTP, UPnP, HTTP,RTSP, DNS client

. Support HTTP Tunneling (RTSP overt HTTP)

. Watch Dog Timer function

. IE Browsing supported (ActiveX?)

. Support NTP time Setting

. Message in e-mail

. Provide RTC (Real Time Clock) function

. Hardware OSD of time display

. USB/SD Card support Alarm Record

. USB/SD Card support Manual Record

. USB/SD Card support Record files Recycle Function

. Support Day & Night function

■ General Features

. HTTP port setting, Audio can be disabled (IE)

. Snapshot, Motion Detect Recording (IE)

. Auto Recovery when disconnected.(IE)

. Programmable IP / Subnet / Gateway (IE)

. Motion Detection Sensitivity: 1~9 (IE)

. Event: Motion Detect, Video Loss(IE)

. Action: E-mail and ftp alarm out. (IE)

. Firmware upgrade over Ethernet (IE)

. Video quality setting: Contrast, Brightness, Saturation, Hue (IE)

. Windows XP/Vista required ( DirectX? 9.0C or Higher)

. Support Windows Internet Explorer 6.0 / 7.0 / 8.0

. Language Support : English, Traditional Chinese

. Support IPCAM alarm trigger (Motion/Digital I/O, Video Loss, Disk Full) by MSN send message.

■ Software Features

. 64 CH Hybrid Software

. CGI, OCX/DLL SDK

. NVR SDK API Code
