. Dimension: 222(L)x143(W)x45(H)mm

. System: SoC Embedded ARM-Linux

. Resolution: NTSC@ 30fps, CIF(352x240),PAL @ 25fps, CIF(352x288)

. Compression: H.264 / MPEG-4 / MJPEG for video

. NTSC / PAL Auto Detection

. Adjustable video data rate

. Adjustable audio data rate

. Synchronized video + audio compression

. Simultaneously multiple clients service more than 5Mbps streaming out Maximum 5 users view.

. Factory setting reset

. Protocol Supported: DHCP, PPPoE, Dynamic DNS, TCP/IP, UDP, SMTP, UPnP, HTTP, RTSP, DNS client, SNMPv1/v2c, SIP

. Support HTTP Tunneling (RTSP over HTTP)

. Provide Dynamic IP server platform for dynamic IP user

. Watch Dog Timer function

. USB 2.0 interface for external storage(HDD) or Pen Drive

. SD support Card Reader function

. IE Browsing supported (ActiveXTM) (Support Verisign)

. Multiple encoders (H.264/MJPEG/MPEG 4, for example), Dual Stream Support at the same time

. Support RS-485 PTZ control

. Support NTP time Setting

. Message in mail

. Support 2-Way Audio function

. Provide Real Time Clock function

. Hardware OSD of time display

. USB/SD Card support Alarm Record(Pre record / Post Record)

. USB/SD Card support Manual Record

. USB/SD Card support Record files Recycle Function

. Support Daylight Saving Time

■ General Features

. Provide scheduling, recording, event list, management, playback, transmitting, recycle

. Provide 1/4/6/9/10/13/16/33/64 CH Window Display

. HTTP port setting, Audio can be disabled

. Snapshot, Motion Detect Recording, I/O Recording

. Auto Recovery when disconnected.

. Support Digital Zoom in/out on Preview and Playback

. Programmable IP / Subnet / Gateway (IE)

. Motion Detection Sensitivity: 1~9 (IE)

. Event: 4 alarm in, Motion Detect, Video Loss, Digital input(IE)

. Action: 4 alarm out, E-mail and ftp alarm out. (IE)

. Firmware upgrade over Ethernet (IE)

. Video quality setting: Contrast, Brightness, Saturation, Hue (IE)

. Windows XP/Vista/7 required ( DirectXTM 9.0C or Higher)

. Support Windows Internet Explorer 6.0 / 7.0 / 8.0

. Support DivX format

. Language Support : English, French, German, Japanese, Italian, Spanish, Simplified Chinese, Traditional Chinese

■ Hardware Specification

. Video Input: BNC x 4 ports

. Video Output: BNC x 1port

. Audio-Input: RCA x 4ports

. Audio-Output x 1port

. Ethernet port: 10/100MBase-T x 1port.

. SD card slot x 1port.

. USB 2.0 Interface x 1port.

. Digital I/O x 4ports

■ Software Features

. 64 CH Hybrid Software

. CGI, OCX/DLL SDK

. NVR SDK API Code

. AXIS Like Firmware

■ Optional Function

. Support 3G Modem Function

. Support Wireless
