1.Fail safe type.

2.Release as power off.

3.With electronics control for over heating.

4.With door monitoring and adjustable door release monitoring time.

5.With adjustable timer to lock.

6.Glass door w/o frame dedicated.

7.With micro switch door position sensor.

Specifications

*Lock size (mm):203(L) x 38(W) x 40(D)

*Approx. weight:2000g

*Nominal voltage:DC12V

*Voltage tolerance: ±10%

*Standby current:220mA

Working current:650mA

*Temp. range:-20°C ~ 70°C

*Power consumption:30W(standby)

8.0W(work)

*Operation:Drop to hold position by magnetic

*Application:For automatic or skid door

We reserve the right to change the specification without notice or obligation!
