•Support data remote download.

•Network protocols include TCP, UDP, IP, ARP, ICMP, Ethernet MAC.

•Convert RS -232C / RS-485 serial interface to Ethernet interface.

•Four LEDs display status information: SYS(PWR), LAN Speed, LAN Rx, LAN Tx.

•With watch dog function.

•Easy installation for wall, desktop or any where mounting.

Auto-detecting Ethernet :

•Connector type: RJ-45 (Female).

•Speed : 10 / 100 Mbps.

•Protocol : TCP, UDP, IP, ARP, ICMP, Ethernet MAC.

•Mode : TCP Server/Client ; UDP Client : Broadcast.

Serial Port :

•Port : RS -232C / RS-485

•Speed : 300bps ~ 921,600 bps.

•Connector type : DB9 (Female).

•RS-232 : TxD, RxD, R TS , C TS , DTR, DSR, GND.

•RS-485 : Data A, Data B.

Specifications

•Dimensions(LxWxH): 115 x 78 x 31mm / 4.5 x 3.1 x 1.2inch

•Enclosure material: ABS

•Power supply: 12V DC, 150mA

•Operation temperature: -15°C ~ 55°C

•Humidity: 10%~90%

•OS: Windows XP / 7 / 8 / 10

We reserve the right to change the specification without notice or obligation!
