•Built-in micro controller for decoding infrared signal to avoid interference from the noise.

•With bi-color status LED (Power on: Red/ Proximity: Blue).

•Adjustable proximity range: 3~10cm (Default: 10 cm), depending on the reflection rate of different object.

•Support adjustable opening time 0.5~20 Sec. (Default: 0.5 Sec.) or latched ON or OFF output.

•With N.C. and N.O. output.

Specifications

•Dimensions: 5(plate)/34(total depth) x 75(W) x 115(L)mm

•Net Weight: 120g ± 5%

•Hole distance: 83mm

•Material: Face plate: Zinc alloy

IR sensor: Polycarbonate fire & UV proof material

•Waterproof: IR sensor:IP65

•Power supply: DC 10V~16V 1A

•Relay contact rating: 1A@ 30 VDC

•Current: DC 12V

Standby Current: 25mA±5%

Operating Current: 35mA±5%

•Operating temperature: -20℃ ~ 75℃

•Life: Mechanical: 3,000,000 cycles

Electrical: 200,000 cycles

We reserve the right to change the specification without prior notice or obligation!
