•Remote release control ranges up to 10 meters.

(For reference only, sensing distance depends on on-site environment)

•With learning mode button for memory up to 40 pieces transmitter ID''''s.

•With LED for indicating power & bolt status.

•Compact structure without additional installation of transmitter receiver and wiring.

•Optional bracket (PG-B64 & PG-DASTC-2) for frameless glass door.

•Electric deadbolt design suitable for double swing door with 180° opening angle.

•With DIP switch for setting time delay for opening & relock door.

•Low working current, no over heating problem.

•Fail safe type released as power off.

Specifications

•Lock size (mm):204(L) x 33(W) x 45(D)

•Approx. weight:687g ±1%

•Nominal voltage:DC11~16V

•Standby current:90~100mA

•Working current:820~870mA

•Temp. range:-20°C ~ 70°C

•Power consumption:1.1W(standby) / 13.9W(work)

We reserve the right to change the specification without notice or obligation!
