1.Fail-secured type released as power on.

2.With magnetic switch door position sensor.

3.With DIP switch for setting time delay for opening & relock door.

4.Electric drop bolt design suitable for double swing door with 180° opening angle.

5.With power & state LED indicator.

6.Low stand by current (18mA) suitable for battery backup in fail secured application.

7.Low working current, no over heating problem.

8.With exit function thru low current contacts.

9.Should be used with Deadbolt releaser DAR-24.

Specifications

1.Lock size (mm):204(L) x 33(W) x 45(D)

2.Net weight: 440g±1% Gross weight: 675g±1%

3.Nominal voltage: DC9V~12V

4.Voltage tolerance: ±10%

5.Standby current: 18mA

6.Working current: 440mA

7.Power consumption: 0.2W(standby) / 5.3W(work)
