1. Adopts the standard Main profile H.264 compression technology,, supports CIF/ D1 recording, Network transmission, and playback Simultaneously

2. Support dual-stream transmission for all channels

3.Support Pentaplex operation: live, record, playback, backup, network transmission,, mobile phone surveillance

4.Support backup with USB Flash Disk, Movable hard disk,USB writer, Network

5.Support 1channel.BNC output, 1channel. VGA output

6. Support Email alarm

7. Mobile phone surveillance (Win CE/Symbian/iPhone/Blackberry)

8. Support PTZ Control

9. Support Multi-language OSD

10. Supports mouse, remote controller, operating

Specifications:

Main Function

Descriptions

Operating system

Embedding Linux OS

Video Compression Format

Main Profile H.264

Video Input

4 Channels BNC

Video Output

1 Channel BNC, Channel VGA(1280*1024)

Display Picture

1/4

Multiplex Operation

Live\display\Playback\Recording\Backup\

Mobile phone Surveillance \Network simultaneously

Display Resolution

PAL:D1(704*576),NTSC:D1(704*480)

Recording Mode

Manual\Timer\Motion Detection\Remote

Recording Frame Rate

D1@25fps,HD1@50fps,CIF@100fps

Recording Resolution

PAL:D1(704*576),HD1(704*288),CIF(352*288)

NTSC:D1(704*480),HD1(704*240),CIF(352*240)

Recording Playback

4 channels playback

Recording Backup

USB,Moved Hard Disk,USB Writer,Network

Network transmission

4 Channels real-time Network transmission with QCIF resolution

Recording Play

Special player

Email Alarm

Send pics to the designated email

PTZ protocol

PELCO-D,PELCO-P

HDD

Support 1 SATA HDD,capacity to 1T

HDD Remain Time Hint

Support

Network and Protocol

RJ-45 10/100M via Ethernet,Support TCP/IP,PPPOE,DHCP,DDNS

IE Browser

Support

Dual Stream

Support(Main and secondary interchange)

Multi-language

Support

Mobile Phone Surveillance

Support Windows\ Symbian\ iPhone\Blackberry Operation System

Mouse Interface

USB1.1

Backup interface

USB2.0

Remoter Controller

Support

Power

DC12V/3A

Working Temperature

0C-50C

Working Humidity

10%-90%

Size

274*214*45mm(L*D*H)
