Our 1:2 SD/HD-SDI Distribution & Amplifier is one economical and compact device and one SDI input and two SDI output simultaneously device with Re-clocking function.

It is a reliable device to split a SDI or HD-SDI video source to two HD-SDI display and amplifier HD-SDI signal to extend the distance up to 200m via RG-6 coax cable.

Feature :

1in, 2out and simultaneously extend distance up to 200M

Video type: HD-SDI, SD-SDI auto -detect

Data Rates: 270Mbps/1.485 Gbps

Support standard: SMPTE 259M, SMPTE 292M

Cable equalization (Belden 1694A) retiming and signal

Re-clocking function capability – unlimited repeater connection

Dual color LED indication of input lock and rate

Pass all ancillary data

Power supply :DC 12V, 1A
