?Input Voltage Range.....................9V DC (Battery)

?Nominal Sens..............................2.3 +/- 1.2 % FT Obscuration

?Heat Sensor Set Point..................115°F

?Operating Temperature..................32°F ~ 100°F

?Relative Humidity..........................0 ~ 95%RH

?Sound..........................................Loud 85 db Alarm Signal

?Test Function...............................Press Testing Button

?Operating Light.............................Monitoring : Every 50S

Alarm Active :Flash

?Escape Light................................Alarm Active :Always

?Material........................................ABS Polycarbonate

?Aux.Relay Rating..........................1A @ 30 VDC / 0.5A @ 125 VAC

?Auxiliary Contact...........................COM : BLUE COLOR

?Auxiliary Contact...........................NO : GREEN COLOR

?Auxiliary Contact...........................NC : YELLOW COLOR

?Auxiliary Contact...........................(+) : WHITE COLOR

?Auxiliary Contact...........................(+) : BLACK COLOR
