*CCD total pixels (H x V): 811 x 508 (NTSC)/795 x 596 (PAL)

*Resolution: 470 TV lines

*Sync system: internal/VD-lock for AC power (select by OSD)

*Minimum illumination:

Legacy mode: 0.8 Lux (F1.2, 5600 degrees K 30 IRE)

Star light mode: 0.008 Lux (F0.8, 5600 degrees K 10 IRE)

*White balance:

Mode: ATW/AWB/FIX (zero color rolling)

Range: 3200 to 10000 degrees K (2200 to 15000 degrees K with S filter)

*Gain control:

Mode: AGC (on/off)

Range: 0 to 18dB

*S/N ratio: 52dB (minimum)/60dB (typical), AGC off

*Electronic shutter: AES: 1/60 to 1/120,000 second (NTSC)/1/50 to 1/120,000 second (PAL)

*Auto IRIS: AES/video-iris/DC-iris

*Selectable by OSD manual: flickerless, mirror, BLC, digital zoom (2X), negative image, masking area, AGC gain adjustment, picture freeze, alarm out (motion detect), color bar, picture enhance, highlight suppress, gamma correction 0.45/1.0

RS-485 IF (no ID)

*Video output: 1.0Vp-p composite video at 75 ohms and Y/C output

*Operation temperature: -20 to 50 degrees Celsius

*Operation humidity: within 85%RH

*Power source: 12VDC and 24VAC/5W
