*The body is made from 5mm-15mm al-alloy material, firm and airproof ;

*Flat designed optical window uses 5mm tempered glass, can prevent distorted images and protect the built-in integrated camera ;

*IP66 waterproof design standard with wiper;

*One pair of IR lamps available, IR distance more than 100 meters.

*Multi installation modes: UP, DOWN , UP30 degree

Camera Features：

* Built-in high resolution integrated zoom camera module

* Black Light Compensation function;

* Color or B&W image switching function;

* Video WDR;

* Video Stabilizer

* Privacy zone masking function, up to 24 privacy zones;

* Video freeze function;

Pan/Tilt Features：

* Step motor with gearbox, accurate position and quick responds;

* Integrated design, attractive appearance;

* Stable operation without dithering and noise;

OSD Menu Features：

* Built-in Chinese/English menu, easy to switch menu between 2 language;

* With OSD passport protect function;

* Support Chinese/English input, can edit title of the user name, camera position and preset position;

* Can set, run, clear presets, preset tours, privacy zone by menu;

* The user name, preset title, inside temperature and pan tilt information display

Built-in Decoder Features：

* Support Pelco P/D;

* Can make software address and hardware address setting;

* Built-in Chinese/English function menu, the function of camera and pan/tilt can be set;

* Check the Pan/Tilt inside temperature real time;

* Power off memory function, can record the movement before power off;

* Powering on self-restoring function: users can assign the camera and pan/tilt movement after powering on;

* Change speed proportionally-Pan/tilt speed and the depth of zoom lens decline proportionally;

* Camera orientation display function(N,NE,E,SE,S,SW,W,NW total 8 orientation, data feedback the PTZ orientation;

* Virtual home position can be set;

* With auto scan and apple peel scan function;

* 2 Pattern track function

* 4 Presets tour function, dwell time can be set;

* 255 preset positions with precision error less than± 0.1o

* 5 channels timer auto-activate function to run the preset movements;
