? The body is made from 5mm-15mm al-alloy material, firm and airproof ;

? Flat designed optical window uses 5mm tempered glass, can prevent distorted images and protect the built-in integrated camera ;

? IP66 waterproof design standard with wiper;

? One pair of IR lamps available, IR distance more than 100 meters.

? Multi installation modes: UP, DOWN

Camera Features：

? Built-in high resolution integrated zoom camera module

? Black Light Compensation function;

? Color or B&W image switching function;

? Video WDR;

? Video Stabilizer

? Privacy zone masking function, up to 24 privacy zones;

? Video freeze function;

Pan/Tilt Features：

? Step motor with gearbox, accurate position and quick responds;

? Integrated design, attractive appearance;

? Stable operation without dithering and noise;

OSD Menu Features：

? Built-in Chinese/English menu, easy to switch menu between 2 language;

? With OSD passport protect function;

? Support Chinese/English input, can edit title of the user name, camera position and preset position;

? Can set, run, clear presets, preset tours, privacy zone by menu;

? The user name, preset title, inside temperature and pan tilt information display

Built-in Decoder Features：

? Support Pelco P/D;

? Can make software address and hardware address setting;

? Built-in Chinese/English function menu, the function of camera and pan/tilt can be set;

? Check the Pan/Tilt inside temperature real time;

? Power off memory function, can record the movement before power off;

? Powering on self-restoring function: users can assign the camera and pan/tilt movement after powering on;

? Change speed proportionally-Pan/tilt speed and the depth of zoom lens decline proportionally;

? Camera orientation display function(N,NE,E,SE,S,SW,W,NW total 8 orientation, data feedback the PTZ orientation;

? Virtual home position can be set;

? With auto scan and apple peel scan function;

? 2 Pattern track function

? 4 Presets tour function, dwell time can be set;

? 255 preset positions with precision error less than± 0.1o

? 5 channels timer auto-activate function to run the preset movements;
