Unique Features：

．A pair of high quality IR lamps: of 100 meter IR distance.


． The body is made from 5mm-15mm al-alloy material, firm and airproof.


． Flat designed optical window uses 5mm toughened glass, can prevent distorted images with greatest extend and protect the built-in integrated camera.


． IP66 waterproof design standard.


． 360degree continuous pan rotation; while 125degree for tilt rotation.


． Multi installation modes: UP,DOWN, UP30degree selectable.


Other Features：


Pan Tilt features：


． Stepper motor with gearbox, stable operation, accurate position and quick responds


． Manual Control Speed for Pan: 0.1o-90o/sec


． Manual Control Speed for Tilt: 0.1o-40o/sec


． Preset Speed: 90o/sec for pan; 40o/sec for tilt.


． Variable pan auto scan speed: 1o-40o/sec available


． Variable Apple peel scan speed: 1o-40o/sec for pan; 1o-20o/sec for tilt


． a pair of IR lamps available, more than 100meters of IR distance


Camera Features：


． Built-in high resolution and variable high zoom camera module


． Black Light Compensation function


． Selectable Color or B&W image function


． Wide Dynamic Video function


． Image Stabilizer function


． Privacy mask function, can support up to 24 privacy zones


． Video Freeze function for high speed presets


Built in Decoder features：


． Integrated multi decoder controller： PELCO P/D protocol


． Chinese/English OSD menu to set the camera and pan tilt function


． Environment checking function, check the inside temperature real time;


Will automatically open the fans once the inside temperature exceed the setting limit value.


． Powering on self-restoring function: users can assign the camera movement after powering on.


． Change speed proportionally function: Pan/tilt speed and the depth of zoom lens decline proportionally and continuously


． The Pan/tilt orientation displays and camera zoom displays variably. Data feedbacks the PTZ orientation.


． With pan auto scan function, the pitching angle can be set


． Virtual home position can be set


． With apple peel scan function


． 2 pattern function


． 4 presets tour function, dwell time can be set


． 255 preset positions with precision error less than ± 0.10


． 5 channels fixed time auto activate function, to run the preset movements


． 3 modes to control the wiper function


． Camera orientation display function（N,NE,E,SE,S,SW,W,NW total 8 orientations）


． 2 alarms input, 1 AUX output


OSD Menu Features：


． Built-in Chinese/English menu, easy to switch menu between 2 languages


． With OSD passport protect function


． Support Chinese/English input, can edit title of the user name, camera position and preset position


． Can set, run, clear presets, preset tours, privacy zone by menu


． Inside temperature and pan tilt orientation information display


Protect Features：


． Embed in surge and lightning protector


． Meeting IP66 standards, CE,ROHS, FCC standards
