．A pair of high quality IR lamps: of 100 meter IR distance.

． The body is made from 5mm-15mm al-alloy material, firm and airproof.

． Flat designed optical window uses 5mm toughened glass, can prevent distorted images with greatest extend and protect the built-in integrated camera.

． IP66 waterproof design standard.

． 360degree continuous pan rotation; while 125degree for tilt rotation.

． Multi installation modes: UP,DOWN, UP30degree selectable.

Other Features：

Pan Tilt features：

． Stepper motor with gearbox, stable operation, accurate position and quick responds

． Manual Control Speed for Pan: 0.1o-90o/sec

． Manual Control Speed for Tilt: 0.1o-40o/sec

． Preset Speed: 90o/sec for pan; 40o/sec for tilt.

． Variable pan auto scan speed: 1o-40o/sec available

． Variable Apple peel scan speed: 1o-40o/sec for pan; 1o-20o/sec for tilt

． a pair of IR lamps available, more than 100meters of IR distance

Camera Features：

． Built-in high resolution and variable high zoom camera module

． Black Light Compensation function

． Selectable Color or B&W image function

． Wide Dynamic Video function

． Image Stabilizer function

． Privacy mask function, can support up to 24 privacy zones

． Video Freeze function for high speed presets

Built in Decoder features：

． Integrated multi decoder controller： PELCO P/D protocol

． Chinese/English OSD menu to set the camera and pan tilt function

． Environment checking function, check the inside temperature real time;

Will automatically open the fans once the inside temperature exceed the setting limit value.

． Powering on self-restoring function: users can assign the camera movement after powering on.

． Change speed proportionally function: Pan/tilt speed and the depth of zoom lens decline proportionally and continuously

． The Pan/tilt orientation displays and camera zoom displays variably. Data feedbacks the PTZ orientation.

． With pan auto scan function, the pitching angle can be set

． Virtual home position can be set

． With apple peel scan function

． 2 pattern function

． 4 presets tour function, dwell time can be set

． 255 preset positions with precision error less than ± 0.10

． 5 channels fixed time auto activate function, to run the preset movements

． 3 modes to control the wiper function

． Camera orientation display function（N,NE,E,SE,S,SW,W,NW total 8 orientations）

． 2 alarms input, 1 AUX output

OSD Menu Features：

． Built-in Chinese/English menu, easy to switch menu between 2 languages

． With OSD passport protect function

． Support Chinese/English input, can edit title of the user name, camera position and preset position

． Can set, run, clear presets, preset tours, privacy zone by menu

． Inside temperature and pan tilt orientation information display

Protect Features：

． Embed in surge and lightning protector

． Meeting IP66 standards, CE,ROHS, FCC standards
