LS-V2359 LS-V2358

LS-V2356 LS-V2355

Image Sensor 1/3" SONY

1/3" SHARP

1/3" CMOS

Horizontal Resolution

600TVL,? ?700TVL, OSD, Effio-E 650TVL,OSD

500TVL 520TVL,IR-CUT

Pixels NTSC:811(H)×508(V) PAL:795(H)×596(V) NTSC:976(H)×494(V) PAL:976(H)×582(V) NTSC:976(H)×494(V) PAL:976(H)×582(V)

PAL:752(H)×582(V) NTSC:768(H)×494(V) PAL:762(H)×504(V) NTSC:762(H)×504(V)

TV System PAL/NTSC

IR LED ￠5X42PCS

IR Series Distance 35M

Lens 2.8-12mm

Sync System Internal

Usable Illumination 0.001 Lux(F2.0)/0LUX IR ?ON? 0.001 Lux(F1.2)/0LUX IR ?ON? 0.001 Lux(F2.0)/0LUX ?IR ?ON

0.8Lux/F2.0? 0.2Lux /F2.0

S/N Ratio ≥52dB (AGC OFF) >52dB(AGC OFF)? >52dB(AGC OFF)? >48dB(AGC OFF)? ≥48dB (AGC OFF)

Gamma Correction 0.45

Video Out 1Vp_p/ 75 Ohms

Scanning System Lntermal

Electronic Shutter Time NTSC: 1/60s~1/100, 000s, PAL: 1/50s~1/110,000s

Operation? Temperature -10℃ ~ +50℃ RH95% Max

Storage? Temperature -20~+60℃ RH95% Max

White Balance Auto

Power Source DC12V (+/-10%)

Dimension 230(L)×86(w)×83(H)mm

Package ?

Weight 1400g
