● Up to 2 concurrent mobility for 3G/4G LTE Link&GPS (2L-1AC model/4 SIMs)

● Built-in 4 GigaT + 2 Dual Speed SFP managed switch including 4 PoE at/af w/budget 80W

● Built-in Managed Switch functions cover port management, QOS, VLAN, multicast, redundant ring and security functionsec

● Dual radio for 802.11ac/a/b/g/n with concurrent 5GHz & 5GHz bands up to 2.6Gbps Wi-Fi bandwidth(2AC model)

● WIFI radio for 802.11ac/a/b/g/n with 5GHz or 2.4GHz; Support WIFI 802.11e traffic prioritization and WMM

● MIMO technology 3T3R up to 6 antenna(2AC); SMA type external antenna

● Support roaming with 802.11k & v

● Supports AP/ Bridge/ Client/ MESH modes

● Support 802.11s Wireless Mesh Network

● Air-teaming** for WIFI high-sustainability and aggregated bandwidth

● Advanced wireless security WEP64/128bits/ WPA/ WPA-PSK (TKIP,AES)/ WPA2/ WPA2-PSK (TKIP,AES)

● VPN router for Multi-site VPN, OpenVPN, L2TP over IPsec, IPsec, PPTP**, L2 over GRE , IPGRE

● Load Balancing built-in 5 mechanisms

● Support NAT and Firewall

● Support Modbus gateway on serial ports

● Support 2 RS422/RS485 ports with 2.5KV isolation or 2x RS232 ports

● Optional EMMC Flash storage on-board**

● Dual Input voltage selection 9~60VDC (24V model)

● Vehicle E-marking* certificate

● Environmental monitoring for router inside info with voltage, current, temperature; Wi-Fi & LTE graphic signal strength

● Editable login page of captive portal for hot-spot application

● USB port to backup, restore the configuration file and upgrade firmware; Dual image firmware*

● ITxPT compliant w/ ignition function*

*Future release **Optional
