Sony 1/3〃 Color CCD 520 TVL Super High Resolution

True Color reproduced by Day

Crystal BW picture at Night

True Color reproduced by day

Crystctal BW piure at night

NO TROUBLE WITH HUNTING BETWEEN BRIGHT AND DARK

High Picture Quality ; High Sensibibility ; High Reliability

Built in 128 pcs  5nm High power LEDS

IR Range : Approx. 120 Meters/393 Ft.

Mechanical IR Filter Built in for Brightness up (Optional)

Extremely Less Noise at Night

Cooling Fan Built in

No any distortion or light halo accrued

Advanced Design for circuitry and mechanism

Easy to Adjust the Focus by open the gate under the Housing

Easy to Install and Connect the Power Cable & BNC Connector from inside of the Bracket

OSD (ON Screen Character Display)

TV System : PAL / NTSC

lmage Area : 4.9mm x 3.7mm (1/3〃 lt CCD, Sony SUPER HAD)

pickup Elements : 510 (H) X 492 (V) 768 (H) X 494 (V)

512 (H) X 582 (V) 752 (H) X 582 (V)

Scanning System : (NTSC) 2:1 lnterlace V:60Hz, H:15.750KHz

Scanning System : (PAL) 2:1 lnterlace V:50Hz, H:15.625KHz

Sync System : lnternal

Video Output : 1Vpp Composite Output,75 ohms.

Minimum Illumination : 0.1 Lux ; 0 Lux (IR LED Activated )

S/N Ratio : 50dB (AGC OFF)

Resolution ( Horizontal ) : 400 TV Lines 540 TV Lines

Lens Mount : C or CS Mount

Camera Adjusted Function : ON SCREEN DISPLAY ( OSD ON the BOARD )

Ambient : 10 ~ 50 / 30 ~ 90% RH

Dimensions(Long Type) : 300(W) X105(H) X 245(L)mm

Weights (Long Type) : Approx. 2100g

Power Source : DC12V ( AC24V/DC12V Dual Power Switching Optional )

Power Consumption : 2.7W(IR Activated 12.5W max )

IR LED Wavelength : 850nm

IR LED : * 128 LEDs (5 High power LED)

Lens : Built in : Manual Vari-focal Lens 6-15mm F1.4

Optional : Vari-focal DC Lens 5-50 mm F1.4

IR CUT Filter : Optional:Control by Microprocessor
