>System: NTSC/ PAL Video System and Video Loss Auto Detection

>Codec: 1,2,..., Maximum fps selectable

Maximum:

NTSC: 30fps@352x240/ 24fps@740x240/ 12fps@704x480

PAL: 25fps@352x280/ 20fps@704x280/ 10fps@704x560

>Record Quality: Low/ Medium/ High

>Record Time:

*It may change for different video content(1GB SD Card)

>Frame Rate@Resolution

30fps@352x240

25fps@352x280

24fps@704x240

20fps@704x280

12fps@704x480

10fps@704x560

Quality

Low: 400 min. 240 min. 240 min.

Medium: 300 min. 150 min. 150 min.

High: 150 min. 75 min. 75 min.

>Recording: Date/ Time Overlay with Video Images in ASF File

>Input: 1 CH Composite Video Line In

>Output: 1 CH Composite Video Line Out

*Audio

>Sampling Rate: 44.1 KHz

>Codec: G.726/ 32kbps

>Input: 1 CH Audio Line In

>Output: 1 CH Audio Line Out

>Storage Media: SD Card (FAT 16/ 32)

>Recording Mode: Manual / Schedule Motion Detection / Schedule Continue

>Motion Detection Setting: Multiple Blocks and adjustable sensitivity

>Event Search Function: Property and first image of selected file is displayed

>Playback Function: Play/ Fast Forward/ Fast Rewind/ Pause/ Step Forward/ Step Forward/ Step Backward

>Playback Speed: x1/ x2/ x4/ x8/ x16/ x32

>Power Supply: DC 5V+- 10% 1A/ 2 x AA (Rechargeable Ni-mH/ Alkaline Battery)

>Battery Lasting Time: 2 x AA Ni-MH: 180 min/ 2 x AA Alkaline :100 min

>Weight: 89 g (without Battery/ SD card)

>Dimensions: 65(W)x 90(H)x 29(D)mm

>Operating Environment: 30%~80% RH, 5C~ 45C (41F~113F)

>Storage Environment : 30%~90% RH, 0C~50C (332F~122F)
