」Support multiple record type, including real time, manual record, motion detection, external alarm, motion & alarm, motion alarm.
」Support PSTN for narrow band dialup.
」Support remote parameters setup.
」Alarm information can be sent to remote center.
」Network control PTZ.
」Network record the real time stream.
」Network download and playback the recorded files in DVR.
」Remote upgrade the firmware.
• Video compression: MPEG4 (H.264)
• Preview resolution: PAL: 704 x 576, NTSC: 704 x 480
• Playback resolution: QCIF/CIF/2CIF/DCIF/4CIF
• Video input:
• K-DVR-8P/8PD: 8
• K-DVR-16P/16PD: 16
• Video input interface: BNC (electrical level: 1.0Vp-p, resistance: 75 ohm)
• Video output: one channel, BNC (electrical level: 1.0Vp-p, resistance: 75 ohms)
• Frame rate:
• PAL: 1/16 to 25fps, NTSC: 1/16 to 30fps
• Monitoring mode: single screen, 4-screen, 9-screen and 16-screen
• Video loop out: no
• Video aux output: no
• Stream type: video/video and audio
• Maximum bit rate: 32Kbps to 2Mbps, self-define
• Audio input:
• K-DVR-8P/8PD: 8
• K-DVR-16P/16PD: 16
• Audio input interface: BNC (linear electrical level, resistance: 1k ohms)
• Audio output: one channel, BNC (linear electrical level, resistance: 600 ohms)
• Audio compression: Ogg Vorbis
• Audio compression rate: 16Kbps
• Alarm output: four relay output
• Voice talk: 1 channel, BNC (linear electrical level, resistance: 1kohm)
• Communication interface: 1 RJ45 10M/100M self-adaptive Ethernet interface, 1 RS232 interface, 1 RS485 interface
• Keyboard interface: 2 RJ45
• HDD IDE interface:
• K-DVR-8P/8PD:
刋 K-DVR-8P: up to 8 HDD
刋 K-DVR-8PD: up to 4 HDD and a DVD-RW
• K-DVR-16P/16PD: K-DVR-16P: up to 8 HDD
• K-DVR-16PD: up to 4 HDD and a DVD-RW
• USB Interface: 1 USB interface, USB1.1, can support USB flash memory, USB HDD and USB CR-R/W
• VGA interface: 1 VGA interface, support resolution: 800 x 600/60Hz, 800 x 600/75Hz, 1024 x 768/60Hz
• External alarm input:
• K-DVR-8P/8PD: 8
• K-DVR-16P/16PD: 16
• Relay output: 2/4
• Power supply: 90 to 135V AC or 180 to 265V AC, 47 to 63Hz
• Power consumption: 20 to 42W (without HDD)
• Working temperature: -10 to +55 degree Celsius
• Working humidity: 10 to 90%
• Size: 19-inch standard ( 450 x 450 x 95mm)
• Weight:8805;8kg (without HDD)
