1/3" Super Hi-Res. CCD Camera

540 TVL/ 0 Lux(IR LEDs on at 2 Lux)

MPEG-4 SP Compression

CIF up to Full D1 Resolution

Two-way Audio Supported

SG-57CDP:

1/3" Sony Super HAD CCD Camera

420 TVL / 0 Lux (IR LEds on at 2 Lux)

CIF up to Full D1 Resolution

Two-way Audio Supported

Image System:

TV System :PAL / NTSC

Image Sensor:1/3-inch Sony Super HAD CCD

DSP:SONY HQ1

Number of Total Pixels:

SG-57HCDP: 795(H) x 597(V)/ 811(H) x 508(V)

SG-57CDP:537(H)x 597(V)/ 537(H) X 505(V)

Resolution: SG-57HCDP:540TVL/ SG-57CDP:420 TVL

Minimum Illumination :0.4 Lux@F2.0(w/o IR)IR LED ON at 2 Lux, controlled by a CDS Sensor

IR LED/ IR Wavelength :24 Unit IR -LED/ Life: 6000 Hours./ 850nm

IR Working Distance :10~15M

IR LED Power Switchable :CDS Auto Cotrol

Electronic Shutter : Automatic, 1/50(60) sec.~1/100,000 sec.

Auto Gain Control :Automatic

Auto White Balance :

SG-57HCDP: Automatic 2,500K ~9,500K

SG-57CDP: 3,200K ~ 9,200K

Signal to Noise Ratio :More than 48dB

Lens Mount:Standard: f4.3mm /F 2.0/ 63 degrees; Options: f3.6mm/ 72.5 degrees,f6.0mm/ 47.5degrees, f8.0mm/ 36.5 degrees

Compression:

Image Compression :MPEG-4 ASP

Image Frame Rate :25fps@720 x 576 :30fps@720x480:25pfs@720x576 :30pfs@720x480

Max Resolution :Full D1/ VGA/ CIF/ QCIF

Network:

Ethernet:10/100 base-T for LAN/ WAN

Supported Protocol :TCP/IP, HTTP, PPPoE, DHCP, RTP/ RTSP, UDP

QoS :Layer 2, 3

I/O Connector :

Network:RJ-45 (WAN/LAN)

Audio Input/ Output :8KHz, Mono, PCM Unbalanced, 1.4Vp-p, 1Vrms, 3.5mm

Serial Port :1 RJ-45 port (RS485)

DI/ O :1xDI ; 1xDO

Software OS Support :Win 2000, Win XP/ 16CH AP

Security: Password Protection: Configuired by the administrator

Power Supply :12Vdc/ POE

Power Consumption :6.0W

Dimensions:106(Dia) x 94.48(L) mm

Weight:320g
