4 Channel Video Transceiver

> Three position range switch for gain select on transmitter.

> Five position distance range switch on Receiver, brightness adjustment, two video output.

> Built in transient protection and ground lifting.

> System is integrated with alarm sensor (PIR, Magnetic, etc...) or RS485/422 data.

TPA016

16 Port Active Receiver Hub In 1U Rack Mounting Panel

> Built in 16 port TTA111VR active receivers in 1U 19" rack mounting panel.

> Built in a highly balanced mode of video transmission for extra interference immunity.

> Built in transient protection and ground lifting.

Video Input Port :16 Port (Terminal Block)

Video Output Port (BNC Connector): 16 Port, 1Vp-p, 75 ohms

Power Input: DC12V

Power Consumption: 500mA

Recommend Cable: CAT 5 Cable 4 Pairs (24 AWG)

Dimension W x H x D mm: 482x170X44 (1U)

Weight: 2720 g

Material: Metal Black

Video Amplifier

CA101

1 input to 1 output Video Amplifier

Wide bandwidth, video gain compensation amplification.

HF compensation.

>>10dB adjustable image gain.

>> Sharpness and Brightness adjustment.

Transmission range: 1000 meters (RG59 coaxial cable)

Red LED: power on/off.

>> It can be connected video camera, multiplexer, VCR, DVR,etc.

Surge Protection Device

Coaxial

SP001

Coaxial Video Surge Protector BNC Connector

Performs a different function than grounding requirements.

Protects equipment from high voltage surges from nearby lightning strikes.

Two stage protection: under 1ns-90V, over 10ns-12V.

Wide range of applications: CCTV/CATV system, Antenna of Television, FM receivers, video camera,

Solution

Provider for video Interference

Video Ground Loop Isolator

GL001

Video Ground Loop Isolator

BNC male to BNC female with mini cable 15 on both sides.

Passive, no power required.

Prevents video-signal distortion caused by video ground loops.

Eliminates picture tearing, cross talk and rolling.

Prevents power cables laid by others interfering with the CCTV system.

Built in TVS (Transient Voltage Suppressors) for surge protection.

monitors, multiplexers & Quad processor, VCR...etc.
