> 1/3-inch SONY Exview HAD CCD

> SONY HQ1/ 540TVL

> Color mode switches to B/W mode

> Mechanical IR cut filter

SG37CH-4,5E

> 1/3" SONY Super HAD CCD

> SONY HQ1/ 540TVL

> Color mode switches to B/W mode

> Mechanical IR cut filter

> TV System: PAL/NTSC

> Image Sensor:

SG32CHE-4,5E: 1/3-inch SONY Exview HAD CCD

SG37CH-4,5E: 1/3-inch SONY Super HAD CCD

> DSP: SONY HQ1

> Number Of Total Pixels(HxV): 795x596(PAL)/ 811x508(NTSC)

> Synchronizing System: Internal

> Resolution: 540 TV Line

> Minimum Illumination:

SG32CHE-4,5E: 0.05 Lux @F 1.0 without IR light; 0Lux with IR light

SG37CH-4,5E: 0.15 Lux @F 1.0 without IR light; 0Lux with IR light

> Day/ Night Switching: Mechanical IR Cut Filter; Color mode automatically switches to B/W mode under 4Lux

> Infra Red Sensitivity: 700~1100nm

> Electronic Shutter Speed Mode: AES ON, AES OFF, 1/50(1/60)sec.

> Back Light Compensation: ON/ OFF

> Automatic Gain Control: ON/ OFF

> Iris Control: Video/ DC

> Auto White Balance: AWB

> Signal to Noise Ratio: More Than 50dB(AGC OFF)

> Video Output: 1Vp-p Composite

> Power Supply: 12Vdc/ 24Vac; 90~260Vac

> Power Consumption: 3.0W

> Operation Temperature: -10 to 50 degrees Celsius

> Operation Humidity: Maximum: RH80%

> Storage Temperture: -20 to 60 degrees Celsius

> Storage Humidity: Maximum: RH90%

> Dimensions: 63(W)x 52(H)x121(D)mm

> Weight: 12Vdc/ 24CVac: 400g; 90~260Vac:550g
