> 0Lux(IR LEDs on at 4 Lux)

> ABW/AGC

> Signal to Noise Ratio to 48dB

> Build in 24 IR LEDs

> Illuminating Distance to 15 M

〈TV System :PAL/NTSC

〈Image Sensor :1/3" SONY Super HAD

〈Resolution:540 TV Line

〈Number Of Total Pixels :PAL:795 (H) X 596 (V) NTSC:811 (H) X 508 (V)

〈Synchronization Mode:Internal

〈Scan System :2:1 Interlace

〈Minimum Illumination:0.4 Lux @F 2.0(w/o IR), 0Lux (w/ IR) IR LED ON at 4Lux, controlled by a CDS Sensor

〈Signal to Noise Ratio:More Than 48dB

〈Electronic Shutter:Automatic, 1/50(1/60) ~ 1/100,000 sec.

〈Camma Control :r=0.45

〈Automatic Gain Control :Automatic

〈White Balance:Automatic 2,500K~9,500K :3,200K~9,200K

〈Video Output:1Vp-p Composite / 75ohm

〈IR LED :24Unit IR-LED/ Life: 6000 Hours.

〈IR wavelength:850mm

〈IR Working Distance :10~15M

〈IR LED Power Switchable :CDS Auto Control

〈Power Supply:DC12V+-10%

〈Power Consumption :IR on:3.6W(300mA); IR off:1.8W(150mA) :IR on:4.2W(350mA); IR off:2.4W(200mA)

〈Lens:Standard:4.3mm/F2.0/ 63; Options:f3.6mm/ 72.5, f6.0mm/ 47.5, f8.0mm/ 36.5

〈Operating Temp. :-10C~+50C / RH85% or less

〈Dimensions:106 (Dia ) X 94.48(L) mm

〈Weight:275g
