*The Latest DSP Technology

*120dB Wide Dynamic Range

*Intelligent Clean spot

*High Contrast Images

*Challenge by Bright Light

*TV System :PAL /NTSC

*Image Sensor :1/3" RGB DPS (Digital Pixel System)

*Number of Total Pixels : PAL:480 TVL NTSC:520 TVL

*Analogy Video Output:1.0Vp-p composite / 75 ohm

*Wide Dynamic Range :120 dB max, 95dB typical

*Minimum Illumination:0 Lux (IR LED ON at 2 Lux)/ controlled by a CDS sensor

*Signal to Noise Ratio:More Than 48dB (AGC OFF)

*Menu:OSD Control

*Occasions:Customized/ Normal/ Indoor/ Outdoor/ fluorescence1/ fluorescence2

*Named Camera:title/ Location

*Brightness Control:ALC/ ELC

*Iris Control :Video/ DC

*Frame PRT. :0:frozen 1:30(25)Frames/Sec. 2:15(12)Frames/Sec.

*Synchronizing System :Internal/ Line Lock

*White Balance :2000K ~ 11000K(Automatic)

*Gain Control :ON / OFF

*Rising illumination :SLOW SHUTTER/ GAIN/ B&W SS

*Day & Night :Day/ Night

*Water Resistance :IP67

*Power Supply:DC12V/AC24V + -10%

*Power Consumption:3.5W MAX

*Lens/ Angle of view(H) :f3.8mm~9.5mm/F1.2 Aspherical D/N Lens/ 74.2~30.0(Standard) f2.5~6mm / F1.3 Aspherical D/N Lens/ 108.2~47.6 (Optioanl)

*Operating Temp. :-10C~+60C / RH 80% or less

*Storage Temp. :-20C~+60C / RH 90% or less

*Dimensions :73(Dia) x 140(H)mm

*Weight :400g
