* 1/3” 2.1-megapixel Sony CMOS
* Full HD resolution 1,080P at 30fps
* 0.02Lux (SENS-UP x30)
* 3-11mm. DC iris megapixel lens (ICR filter change)
* Built-in OSD controller and 2nd BNC cable
* Concealed 3-axis bracket
* 2DNR/3DNR Level (0~100) adjustment setting/smart NR
* IP66-rated for outdoor application

* SDI Tx Chip: TI(LMH0030)
* Image Sensor: 1/2.9” Sony EXMOR (IMX122)
* Minimum Illumination: 0.02LUX(X30 SENS_UP)
* Video Setting: Day/Night : EXT, ATW, Sens_up X2, 3DNR(84)
* S/N Ratio: More than 50dB
* Image Resolution: 1920x1080 @30fps
* Max. Power Consumption: Max 10W
* Power Input: DC 12V(10%), Option(AC24V)
* Interface: RS_485(Pelco_D), CVBS
