Picture Element : NTSC:768 (H) ⊙ 494 (V)

PAL:752 (H) ⊙ 582 (V)

Scanning Frequency : NTSC: 15734Hz (H), 60Hz (V)

PAL: 15625Hz (H), 50Hz (V)

H. Resolution : 520 TV lines

Illumination 0 Lux (IR ON)

Lens Mount : 6mm Board Lens (4/8/12mm Optional)

IR Led : 30 pcs

IR Distance: 20 Meters

Synchronizing : Internal Sync., 2:1 Interlace

Auto White Balance : AUTO

Auto Gain Control : AUTO

Backlight Compensation : AUTO

S/N Ratio : More than 48dB

Gamma Correction : 0.45

Auto Shutter : AUTO1/60 (50) ° 1/100,000

Video Output : 1.0Vp-P75

Water Proof : IP 67

Power : DC 12V/320mA

Dimension : 68(O)x125(D)mm

Weight : 600g

Operating Temperature : ⌒10°∠45
