* Model No. JSTZ3902
* Power Supply: 110V or 220V ±10% 50Hz/60Hz
* Working temperature: -25°C ~ 65°C
* Relative Humidity: 95% no condensation
* Open/Close Speed: 0.4~1.0s Adjustable
* Power Rating: 100W
* Input Interface: DC 12V level signal or pulse signal, pulse width >100ms, driving current > 10mA
* Communication interface: RS485 standard
* Communication distance: maximum 1200m
* Operation Noise: ? 65dB
* Lane Width: 600mm
* Pass Speed: 20-30people/minute (Normal Open Mode), 15-20people/minute (Normal Close Mode)
* MTBF: 3million times
* Application: Indoor
* Dimension: 1500mm (L)*120mm(W)*960mm(H)
