360 degrees continuously pan, 90 degrees in tilt, 180 degrees in auto flip

Auto pan scan:

Horizontal scan automatically, three-dimensional scan between two presets

Call OSD function by manual

Menu call and zoom manually

Unique ID,can achieve remote address control

Tour through preset in groups, can apart into four groups, max 32 presets in each group

Tour speed is adjustable

Dwell time is changeable

Pelco P or D can be identified automatically

Activity function:

Auto park function

Restore function, auto protection is on when power is cutting

Privacy zone function (applied tos1 to 18C, S1 to 18B, H23BW, S3 series camera)

Proportional controlling function

Hold looking function

Technical data:

Voltage: 24V AC (±20 %)/12V DC(±20 %)

Consume voltage:

Outdoor: ≤30W (including auto temperature control function)

Indoor: ≤20W

Turn speed:

Pan: 0.1 to 240°/s (manual) call preset 240°/s

Tilt: 0.1 to 120°/s (manual) call preset 120°/s

Turn scale:

360° continuously pan

90 ° in tilt

Work temperature:

-35 to 50?C (outdoor) (no condensation)

-10 to 50?C (indoor) (no condensation)

Communication format: standard RS485 (mians) (half duplex)

Baud rate: 1,200, 2,400, 4,800 and 9,600
