All weather design

Built-in auto heater

Built-in decoder, 0 to 255 address can be set

Maximum 63 presets, programmable

Auto touring function (fore 16 presets)

Auto scanning function

Adopt to the controlling of integrated camera

Adopt to the controlling of the lens (variable focal length, focus, iris) with presets

IR camera system is compatible

Material: Aluminum alloy

Waterproof, oven-resistant and cauterization-resistant

Motor with excellent function

Technical Specification:

Input voltage: AC 24 (± 10%)

Consumed power:

PTZ: 20W

Temperature controller: 15W (optional)

Turn speed: (pan) 5.6° /s, (tilt) 3.6° /s

Turn angle: (pan) 0 to 355° /360° Continuously, (tilt) -70 to 20°

Address scale: 0 to 255

Preset: (maximum) 128

Preset accuracy: ± 0.3°

Communication format: RS485

Communication protocol: Pelco-P, D

Baud rate: 1200/2400/4800/9600BPS

Output power: DC 12V (± 10%)/800mA

Camera control interface: RS-485/RS-232/level control

Protection grade: IP66

Working temperature: -10 to 50° C, -30 to 50° C (with internal heater) optional/<90° (non-condensing)

Maximum load: 18kg (state standards)

Maximum tilt torsion moment: 21.2Nm (state standards)

Weight: 8.5kg
