Adopt DC brushless machine and the drive mode of gear reducer

Multi-mast the PTZ, flexible and convenient

Prompt response without lag

High intensity aluminum alloy casing

Technical Specification:

Input voltage: 24V AC 50/60Hz

Consumed power: ≤ 60W

Turn angle:

Pan: 0 to 350 degree

Tilt: -80 to 60 degree

Turn limit:

Pan/tilt degrees: Adjustable

Turn speed:

Pan: 0 to 30 degree /s

Tilt: 0 to 15 degree /s

Presets: Maximum 128

Presets precision: 0.1 degree

Communicate format: RS-485

Communicate protocol: Pelco-P and D

Baud rate: 1, 200/2, 400/4, 800/9, 600BPS

Control mode for housing: Level control, UART, and RS-485

Address: 1 to 255

Working temperature: -30 to 55 degree C

Maximum loading: 15kg

Weight: 8.5kg
