High-intensity aluminum alloy material, enhanced capability of impact resistance, shielding, heat dissipation

Adapts brush DC motor and drive mode of gear reducer, insure stability, prompt response, flexible operation, energy efficiency and environment-friendly

Protection grade: IP66, special surface treatment can meet three proofing requirements

Technical Specification:

Input voltage: DC12V (± 10%), Exterior power:AC220V turn DC 12V 4A

Power consumption: 10W

Turn angle: Tilt: -70 to 20°,Pan:0~360°

Turn speed:

Pan: 0.8 to 35° /s

Tilt: 0.8 to 20° /s

Preset: 0 to 255

Preset precesion:± 0.5

Built-in protocol: Pelco-P or Pelco-D

Baud rate: 1200/2400/4800/9600BPS (optional)

Working temperature: -20 to 55° C at <90%RH (non-condensing)

Maximum loading capacity: 5kg (state standards)

Weight: 2.75kg

Camera control interface: RS-485

Continuously pan: 360°

Built-in protocol Pelco-P or Pelco-D

Baud rate 1200/2400/4800/9600BPS (optional)

Maximum loading capacity of Pan Tilt 5kg
