High intensity aluminum alloy casing. Waterproof, heat resistant, ageing resistance,

Anti-corrosion. Designed for all-weather environment.

Adopts DC brushless machine and the drive mode of gear reducer, insure stability, promote response, flexible operation, energy saving and Rohs, can use solar power for electricity.

L Built-in intelligent decoder, high precision orientation, tour through presets in groups, realize the closed loop control of position velocity, no self-checking after power-on.

Auto routing inspection function

Auto scan function/Three-dimensional scan between two presets

With the data returning function, can be linked with other boot device

Multi-mast the PTZ, flexible, convenient. Prompt response without lag.

Pretection grade IP66, special surface treatment can meet three proofing requirements

Technical Data

Input voltage: AC24(± 15%) 50/60Hz

Consumed power: ≤ 200W

Turn Angle: Pan: 0 to 360 degrees Tilt: -60 to+ 60 degrees

Turn Speed: Pan: 1-12 degrees/s Tilt: 0.5-6 degrees/s

Presets: Max 220

Presets Precision: ± 0.1 degree

Communicate Format: RS-485

Communicate Protocol: Pelco P, D

Baud Rate: 1200/2400/4800/9600BPS

Address: 1-255

Work Temperature: -30 - +55° C

Maximum Loading: 40kg

Weight: 14.5kg
