External interface

Video output:1 route CVBS analog output

RS485:1 route,support transparent channel connection

Ethernet:1 route RJ45 10M/100M auto adapt to ethernet port

Software

Network protocol:TCP,UDP,IP,HTTP,DHCP,RTSP,FTP,SMTP,DNS,DDNS,NTP,ONVIF

Web browser:Microsoft Internet Explorer 6.0 or above version

SDK:Support

Safety:password protection,administrator authority

Electrical specification

Supply voltage:AC 24V(±10%) 50/60 Hz

Consumed power: PTZ:60W,Heater:26W(optional)

Pan tilt

Pan turn speed: 0.8-18°/S

Tilt turn speed: 0.3-7°/S

Pan turn scale: 0~355°

Tilt turn scale:-80°~+60° (pan and tilt angle can adjustable)

Address scale:0~255

Preset NO.:Maximum 128

Preset precision:± 0.1°

Communication format:RS-485

Protocol:Pelco-D/P protocol

Baud rate: 1200/2400/4800/9600bps optional

Others

Working temperature:-10℃-＋50℃,-30℃-＋50℃(with heater)/<90%(non-condensing)

Material:High-intensity Aluminium Alloy

Driving mode:DC brushless motor, gearing drive

IP protection:IP 66

Technical data ( SDI version)

Camera

CMOS Sensor:1/3 CMOS Sensor

Effective pixels: 1920(H)x1080(V)

Scanning mode:16:9

Sync system: inter-sync

Horizontal resolution:1000 TVL

Minimum illumination:0.5 Lux(day),0.1Lux(night),0.002Lux(open DSS)

Video Output: digital output (LVDS) HDMI,HD-SDI/ analog output (CVBS)

Lens type:20x optional zoom,32x digital zoom

Focal length:f=4.7mm~94mm,F1.6(Wide)~F3.5(Tele)

Focus:auto/manual/Keyboard/auto

Focus distance:0.1/0.5/1.0/3.0/6.0/10.0M

Exposure mode:auto/shutter priority/iris priority/Manual

Electronic shutter:1/30(25)~1/60,000 Sec

BLC:WDR/BLC/OFF

Day night switch: auto/day night outer-sync

White balance:auto/manual/outdoor/indoor/keyboard/auto

DNR:auto/off/low/middle/high

Privacy block: 24 area

Motion detection:4 area

Supply voltage: DC 9V-15V

Consumed power:Maximum 5W

Working temperature:-10℃-＋50℃
